PowerVision PowerEgg

KEY FEATURES: Revolutionary design, feature-rich and intuitive with a unique eggshaped exterior. The PowerEgg Maestro™, a gesture-based one-handed controller with motion-sensing capabilities, allows users to interact with and manipulate the drone in flight.  xplore from a distance with real-time HD video transmission of up to approximately 5 km. 360° panoramic 4K UHD camera on a 3-axis gimbal captures stabilized, unobstructed aerial views.

Included accessories:

• PowerEgg Remote Control

• PowerEgg Base

• Station
• PowerEgg Smart Battery
• PowerEgg Charger
• PowerEgg Maestro Controller
• PowerEgg Stand

DIMENSIONS:

Product: 272 x 176 mm (closed) / 272 x 476 mm (flight)

Weight with battery: 2,100 g.

Packaging: 340 x 340 x 200 mm, 5,900 g.

Colour: White

---

AIRCRAFT

Weight: 2,100 g (4.6 lb) (Battery and propellers included)

Diagonal Size: 448 mm

(Excluding Propellers)

Physical Dimension:  272 mm x 176 mm (Close) / 272 mm x 476mm (Flight)

Max Ascent Speed: 5 m/s (Professional mode)

Max Descent Speed: 2 m/s (Professional mode)

Hover Accuracy Vertical: +/- 0.1 m (When Vision Positioning is active, 0.3 - 3.5 m); +/- 1 m

Horizontal: +/- 0.2 m (Surface with clear pattern and adequate lighting); +/- 1.5 m

Max Flight Speed: 13 m/s (Professional mode)

Operating Frequency: 2.4 GHz

Propellers Size: 10.5 inch

Power: 265 W (Hover) 450 W (Max)

Max Flight Time:  Approx. 23 min

Max Attitude: 30 degrees

Max Service Ceiling: 4,000 m (13,123 ft)
Above Sea Level

Operating Temperature: 0° - 40°C (32° - 104°F)

GPS Mode: GPS and BeiDou

Wind Resistance: < 5 level

GIMBAL

Controllable Pitch: 0°-90°
Range

Controllable Yaw: -120° - +170°
Range

Stabilization: 3-axis (Pitch, roll, yaw)

Controllable: 0.05°
Accuracy

STANDARD REMOTE CONTROLLER

Operating: 0-40° C(32° - 104°F)
Temperature

Battery: 3000mAh LiPo 1S

Operating Voltage: 120mA/3.7V

Operating Life: 20hours

Charging Time: 3.5hours

POWEREGG MAESTRO™ MOTION REMOTE CONTROLLER

Operating: 0-40° C(32° - 104°F)
Temperature

Battery: 1,500mAh LiPo 1S

Operating Voltage: 120mA/3.7V

Operating Life: 10hours

Charging Time: 2hours

OPTICAL POSITIONING

Velocity Range: ≤ 4 m/s (2 m above ground)

Altitude Range: 0.2 - 3.5 m (0.66 – 13.12 ft)

Operating: Surface with clear, pattern and adequate

Environment: lighting (Lux > 15)

CHARGER

Input: AC 100—240V

Frequency: 50/60Hz

Output Port 1: 16.8 V ± 0.1 V < 5 A

Output Port 2: 5 V ± 0.1 V  < 6 A

Operating: -10° - 45°C (14° - 113°F)
Temperature

Rated Power: 114W

CAMERA

Sensor: 1/2.3" CMOS

Lens: FOV 95° 15 mm (35 mm format equivalent) f/2.8

ISO Range: 100 - 1,600 (Photo)
                    100 - 1,600 (Video)

Shutter Speed: 8 s to 1/8,000 s

Image Max Size: 4,254 x 3,264
                              2,840 x 2,160
                              2,560 x 1,920

Still Photography Modes: Single shot
                                              Burst shooting: 3 / 5 / 10 frames
                                              Auto Exposure Bracketing (AEB)
                                              3 / 5 / 7 at 0.3 EV Bias
                                              bracketed frames
                                              Self-timer: 5 / 10 / 30 s
                                              Time-lapse: 1/30
                                              1, 2, 5, 10, 20, 30, 60 s
                                              UHD: 3,840 x 2,160

Video Recording Modes: FHD: 1,920 x 1,080
                                             HD: 1,280 x 720
                                             Micro-SD

Supported SD Card: Max capacity: 64 GBClass 10 or UHS-1
Types

Max Video Bitrate: 60Mbps

Supported File Formats: FAT32/exFAT
                                            JPEG, DNG
                                            MP4, MOV (MPEG-4 AVC/H.264)

Operating Temperature: -10° - 40°C (14° - 104°F)

BASE STATION

Operating: Aircraft to Base Station: 2.400 - 2.483 GHz

Frequency:  Base Station to other devices: 5.745 GHz -5.825 GHz

Max Transmissions: 5 km (3.1 mi) (Subject to regulation and local operating conditions).
Distance                     Distance will be shorter for CE.


Operating: 0° - 40°C (32° - 104°F)
Temperature

Battery: 2,300 mAh LiPo 1S

Transmitter: 20 dbm @ CE, 28 dbm @ FCC
Power

Operating Voltage: 800 mA / 3.7 V

Operating Life: 2 hours

Charging Time: 5 hours

Latency: 300 ms

POWEREGG SMART BATTERY

Capacity: 6.4AH

Voltage: 14.8V

Battery Type: LiPo

Energy: 94.8WH

Net Weight: 580 g (1.3 lb)

Operating: -10° - 40°C (14° - 104°F)
Temperature

Charging Current: 2C
